0-5 Vdc output, 0-100 to 0-30K psi, Solid Machined Sensor
Viatran’s 24B is one of our most versatile pressure transducers for industrial applications. The 24B measures from 0-100 PSI to 0-30,000 PSI with standard linearity of ≤ ±0.25% FSO.
Features
All Stainless Steel construction
Shunt Calibration circuit option
RoHS Compliant
Viatran’s 24B is one of our most versatile pressure transducers for industrial applications.
The 24B measures from 0-100 PSI to 0-30,000 PSI with standard linearity of ≤ ±0.25% FSO.
Full Scale Pressure Ranges: 0-100 thru 15,000 PSIG (PSIS FOR ≥ 1500 PSI) (7 thru 1000 bar)
Nonlinearity (Best Fit Straight Line): ≤±0.25% FSO
Hysteresis & Repeatability: ≤±0.10% FSO
Full Scale Output (FSO): 5 Vdc at 70°F (21°C) ≤±0.10% FSO
Resolution: Infinite
Long Term Stability: ≤±0.3% FSO per 6 months
Compensated Temperature Range: 70°F to 170°F (21°C to 77°C)
Process Media Temperature Range: -40°F to 250°F (-40°C to 121°C)
Ambient Operating Temperature Range: -40°F to 185°F (-40°C to 85°C)
Storage Temperature Limits: -40°F to 250°F (-40°C to 121°C)
Temperature Effect on Zero: ≤±2.0% FSO per 100°F
Temperature Effect on Span: ≤±2.0% FSO per 100°F
Supply Voltage:
- 8 to 30 Vdc at 3.5 mA nominal, 5 mA max
- (12 to 30 Vdc for 10 Vdc output option)
Power Supply Regulation: ≤±0.01% FSO per volt change over the supply voltage range
Output Signal: 0 – 5 Vdc standard (see options)
Zero Adjustment: ±5% FSO min
Circuit Protection: Input polarity may be reversed. Output may be short-circuited indefinitely (Over voltage protection to 1000 volts according to EN61000-4-5)
Insulation Resistance: <5 nSec to case ground
Response Time: <2 mSec to reach 90% of full scale
RFI / EMI Suppression: CE EMC compliant per IEC EN 61326. CE marked
Electrical Connection: Bendix PT02E-10-6P, mates PT06E-10-6S (SR)
Pin Outs:
Pin A + Power
Pin B – Power
Pin C + Signal
Pin D – Signal
Pin E No connection
Pin F No connection
Shell Ground
Wetted Parts: 15-5 PH stainless steel
Housing: 304L SS
Weight: 10 oz (283 g)
Identification: Pressure sensitive label
Pressure Connection: 1/4″ – 18 NPT female
Proof Pressure: 1.5 times range or 20,000 PSI (1379 bar) max
Burst Pressure: 3 times range or 35,000 PSI (2400 bar) max
Pressure Cavity Volume: 4.5 ml
Mounting: May be supported by process piping
BF: (K)PTIH-10-6P
BG: DIN 43650
BL: WK6-32S
BN: (K)PTIH-8-4P
BQ: (K)PT02H-10-6P
BR: CF3102E-14S-6P
ZU
DA: Isolated shunt
DC: Extended Compensated Temperature Range (Cold) -40°F to 170°F (-40°C to 77°C)
DG: Improved temp performance to 0.005% FSO per 1°F
DH: Special ranging
DK: Special shunt calibration setting
DM: Modified full scale output
DN: Improved non-linearity
DQ: Cleaning for oxygen service
EA: Special calibration run
EH: Extended Compensated Temperature Range (Hot) +70°F to 185°F (21°C to 85°C)
NH: Customer specified identification
PW: 1/8 DIN digital indicator
TW: GOST-R
Y():
- Multiple pressure ports available. Consult our engineering.
- Direct Cable (175°F max temperature) (79°C)
Note:
Application of some available options may affect standard performance.
